Drive Axle for Forklift

Forklift Drive Axle - A forklift drive axle is actually a piece of machinery that is elastically fastened to a vehicle frame utilizing a lift mast. The lift mast is attached to the drive axle and is capable of being inclined around the axial centerline of the drive axle. This is accomplished by no less than one tilting cylinder. Forward bearing elements together with rear bearing components of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle could be pivoted around a swiveling axis oriented horizontally and transversely in the vicinity of the back bearing components. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the vehicle framework and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Forklift units like H35, H40 and H45 which are made in Aschaffenburg, Germany by Linde AG, have the lift mast tilt capably attached on the vehicle framework. The drive axle is elastically affixed to the forklift framework by numerous bearing tools. The drive axle consists of tubular axle body along with extension arms affixed to it and extend backwards. This particular type of drive axle is elastically affixed to the vehicle frame utilizing rear bearing parts on the extension arms along with frontward bearing devices situated on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the vehicle from the other bearing device in its respective pair.

The drive and braking torques of the drive axle on tis particular model of forklift are sustained using the extension arms through the rear bearing components on the framework. The forces generated by the lift mast and the load being carried are transmitted into the floor or roadway by the vehicle framework through the front bearing elements of the drive axle. It is essential to ensure the components of the drive axle are installed in a rigid enough method to be able to maintain immovability of the lift truck truck. The bearing components can reduce minor road surface irregularities or bumps through travel to a limited extent and offer a bit smoother operation.
